Universal Tower Bimini Top
26” High – 5’ long Available in 4 sizes to fit virtually any tower configuration.
View Fabrics and Color Options
Available Fabrics
Sunbrella®
Superior Quality
100% Solution Dyed Marine Acrylic 9.25 oz Highly UV and mildew resistant. Excellent resistance to fading and rot. Extremely water repellent. Excellent sun blockage. Endorsed by the American Cancer Society. Made in USA. (10 Year Limited Warranty)
Color Options
Striped
Superior Quality
Now available with stripe.
Color Options
*Sunbrella® is a Registered Trademark of Glen Raven Mills
*Performance Poly-Guard® is a Registered Trademark of Carver Industries
*Sun-DURA™ is a Trademark of Carver Industries
*Mossy Oak™ is trademark used under license from Haas Outdoors, Inc. by Carver Industries, Inc.
Design
Tubing
7/8" heavy-wall anodized aluminum tubing
High Grade Domestic Nylon
Fittings standard.
Stainless Steel
Snap hooks and eye straps.
316 Grade Stainless Steel
Adjuster buckles and assembly fasteners.
Canvas Binding
100% marine-grade acrylic.
Weather-Resistant
Anti-wick thread used throughout canvas construction.
Professional stitching
No raw edges.
Best Warranty
Best warranty in the business based on fabric selection.
Made in the USA
All Carver Covers are made in the USA.
Product Details
Our universal tower clamps accommodate a wide range of tower diameters from 1-7/8” up to 2-3/8” making our tower bimini among the easiest to install. Available only in our premium Sunbrella® 100% marine acrylic with matching zippered storage boot and 7/8” heavy-wall anodized aluminum tubing. Each tower bimini comes standard with one set of tower clamps, high grade domestic black nylon fittings and front and rear hold down straps. Hold down straps may be replaced with optional braces (sold separately, see part numbers below).
Acrylic Part Numbers – Solid Canvas Acrylic Part Numbers
| Fits Widths | Ready to Assemble | Fully Assembled |
|---|---|---|
| 66” to 74” | A2670UBD | A2670TBD |
| 74” to 82” | A2678UBD | A2678TBD |
| 82” to 90” | A2686UBD | A2686TBD |
| 90” to 98” | A2694UBD | A2694TBD |
Acrylic Part Numbers – Striped Canvas
| Fits Widths | Ready to Assemble | Fully Assembled |
|---|---|---|
| 66” to 74” | A2670UBDST | A2670TBDST |
| 74” to 82” | A2678UBDST | A2678TBDST |
| 82” to 90” | A2686UBDST | A2686TBDST |
| 90” to 98” | A2694UBDST | A2694TBDST |
Note: Add Acrylic Color Code to complete your part number (see above for striped colors or see catalog for solid colors).
Optional braces are available as an upgrade to standard hold-down straps. Braces are 24” long and are sold in pairs. Each pair of braces comes complete with tower clamps.
Single Brace Kit (front or rear) – Order No. OPT1D
Dual Brace Kit (front and rear) – Order No. OPT2D
Download the Universal Tower Top Information Sheet
